BRISTOL Single Leaf Fire Rated Steel Door with Frame (BS 120 Minutes)

• Door Type: Single leaf steel door with frame
• Fire Rating: BS 476 Part 22:1987 – 120 minutes fire resistance
• Dimensions: Width 1219 mm × Height 2133 mm
• Jamb Depth: 150 mm standard; excess depth may affect pricing
• Leaf Thickness: 44 mm
• Leaf Edge Type: Single rebate
• Leaf Infill Material: Honeycomb core for strength and insulation
• Leaf Sheet Thickness: 1.5 mm galvanized steel
• Frame Sheet Thickness: 1.2 mm galvanized steel
• Frame Profile: Lockformed for superior rigidity
• Finish: Polyester powder coated for corrosion and impact resistance
• Color: RAL color to be confirmed (standard: RAL 9010, 9002 – non-metallic)
• Brand: BRISTOL
• Hardware Set: SET-A (D&D and Dortec branded hardware)
• Installation: Excluded from pricing (site measurements not included)
• Size Changes: Buyer responsible for changes after confirmation
• SS Hardware Grade: All stainless steel components are 304 grade

• Hardware Details – SET-A (Per Door)
• DDSS001 Ball Bearing Hinges (4″x3″x3mm) – SSS: 4 pcs – Brand: D&D
• DT-F1500RA Touch Panic Latch – SIL: 1 pc – Brand: Dortec
• DT-H109TU External Trim – SSS: 1 pc – Brand: Dortec
• DDDC018 Door Closer – SIL: 1 pc – Brand: D&D
• DDDS001 Door Stopper – SSS: 1 pc – Brand: D&D
• Please note, if you want to open an LC and import yourself, we will handle all arrangements for you, Ex-Works Dubai price at $418
• Prices in PKR shown by us are Including items prices & 95% Taxes/Customs & Excluding Freight Charges.

BRISTOL DOOR STANDARDS
NFPA COMPLIANT
BM TRADA
INTERTEK
BS 476
BS EN 1154 and BS 8300
CE CERTIFIED
BS2972
ASTM C-209
BS 874
BS 3638
ISO 354
ASTM C 423
BS 476
ASTM E-136
ASTM E-84

• For more information, visit our website: https://silverstringchemicals.com/
• Connect with us on social media:
• LinkedIn: Silver String Chemicals
• TikTok: @silverstringchemicals
• YouTube: Silver String Chemicals
• Instagram: @silverstringchemicals_ssc
• Facebook: Silver String Chemicals
• Contact us via email at: silverstringchemicals@gmail.com

BRISTOL Single Leaf Fire Rated Steel Door with Frame (BS 120 Minutes)

Reliable Fire Protection Compliant with BS 476 Part 22:1987

Introduction: High-Performance Fire Rated Door for Maximum Safety

The BRISTOL Single Leaf Fire Rated Steel Door with Frame delivers a dependable and durable solution for protecting buildings from fire. With a 120-minute fire resistance rating as per BS 476 Part 22:1987, this door blocks flames, smoke, and heat—giving occupants critical time to evacuate and emergency teams time to respond.

Whether installed in commercial, industrial, or residential settings, the BRISTOL fire door ensures uncompromised safety while maintaining an elegant, professional look.

Key Features of the BRISTOL Fire Rated Door

1. Door Type: Single Leaf with Integrated Frame

This door features a single-leaf design paired with a built-in steel frame. It offers easy access in limited-space areas while maintaining high fire resistance.

• ✅ Space-Saving Entry: Ideal for narrow corridors or high-traffic zones

• ✅ Integrated Frame: Increases stability under fire conditions

2. Certified Fire Rating: 120 Minutes – BS 476 Part 22:1987

Tested and certified to withstand fire for 2 hours, this door meets global safety expectations.

• 🔥 120-Minute Protection: Helps isolate fire, smoke, and heat

• 📜 BS Standard Compliant: Meets stringent British fire safety codes

3. Standard Dimensions: Ready for Most Installations

The standard door size measures 1219 mm (W) × 2133 mm (H), providing a safe yet functional passage for personnel and equipment.

• 📏 Universal Fit: Suitable for industrial units, hospitals, offices, and more

• 📦 Efficient Sizing: Balances access and fire containment

4. Infill Core: Honeycomb for Strength and Insulation

The door leaf uses a honeycomb core, which strengthens the structure and insulates against heat. It also enhances acoustic control, making it suitable for noise-sensitive areas.

• 🧱 Thermal Barrier: Slows heat transfer

• 🔇 Soundproof Benefit: Minimizes noise in commercial buildings

5. Sheet Thickness: Heavy-Duty Galvanized Steel

Built for performance, the leaf uses 1.5 mm and the frame uses 1.2 mm thick galvanized steel. This provides long-term protection against impacts, corrosion, and structural warping.

• 🛡️ Leaf: 1.5 mm galvanized steel

• 🏗️ Frame: 1.2 mm galvanized steel

6. Lockformed Frame: Extra Rigidity Under Stress

The lockformed frame profile adds rigidity and minimizes flexing under heat or pressure. It ensures structural consistency during fire incidents and mechanical stress.

• 🧩 Tightly Bonded Joints: Reduce weakness and failure points

• 🔒 Enhanced Security: Keeps the door solidly in place

7. Finish: Polyester Powder Coating for Clean Look & Protection

The door comes with a durable powder-coated finish, adding corrosion resistance and a professional appearance. It also supports easy cleaning and long-term surface protection.

• 🎨 Sleek Finish: Smooth, scratch-resistant, and maintenance-friendly

• 🌦️ Weather Protection: Suitable for indoor or sheltered outdoor use

8. Color Options: Match Your Design Needs

Standard options include RAL 9010 (Pure White) and RAL 9002 (Grey White). Custom RAL colors are available upon request to match your building’s interior or branding.

• 🎯 Customizable Palette: Choose the right color for any space

• 🏢 Visual Consistency: Maintain architectural harmony

9. Hardware: Premium Stainless Steel by D&D and Dortec

Fitted with SET-A branded hardware, all components are made from SS 304 stainless steel. These high-quality parts ensure smooth operation, rust resistance, and lasting durability.

• 🛠️ Premium Brand Fittings: Trusted for fire safety systems

• 🔧 Durable Hinges, Locks, and Handles: Built to perform under heat and pressure

Installation Notes and Buyer Responsibility

While the door comes fully manufactured and hardware-ready, the installation service is not included. The buyer must ensure accurate site measurements. Any size changes after order confirmation are also the buyer’s responsibility.

• 📌 Clear Opening Reference: Match structural dimensions precisely

• 🚫 No On-Site Alterations Included: Confirm all specs before placing an order

Where to Use the BRISTOL Fire Rated Door

This door is suitable for multiple fire safety applications:

• 🏢 Commercial Buildings: Offices, hospitals, shopping malls

• 🏭 Industrial Sites: Warehouses, factories, and production facilities

• 🏘️ Residential Complexes: Apartments and gated communities

• 🚨 Fire Compartments: Firewalls, stairwells, and exits

Conclusion: Reliable Protection You Can Trust

The BRISTOL Single Leaf Fire Rated Steel Door with Frame is more than just a door—it’s a critical fire safety barrier. With 120-minute protection, robust steel construction, and premium SS hardware, this door is engineered for performance in high-risk environments.

From aesthetics to safety compliance, it covers every essential. Choose BRISTOL when safety, durability, and quality matter most.
