Description
Vertical Turbine Pumps 500 GPM 9 bar China
General:
- Flow Rate: 500 GPM (113.5 m³/h)
- Head: 9 Bar (90 meters)
- Pump Type: Vertical Turbine Pump
- Application: Fire Protection, Water Supply
Pump:
- Model: EA65-32GC (or equivalent)
- Material: Stainless Steel/Cast Iron
- Impeller: Closed/Semi-Open
- Stages: 3-5 (based on head)
- Shaft: Stainless Steel (AISI 304/316)
- Seal: Mechanical Seal (optional: double seal)
Motor:
- Type: Three-Phase Induction Motor
- Model: Y250M-2 (or equivalent)
- Power: 55 kW
- Speed: 3000 RPM
- Voltage: 400V, 50Hz
- Protection: IP55
- Efficiency: IE3/IE4
Performance:
- Efficiency: ≥80% at rated flow/head
- NPSH: 3-5 meters (site-specific)
- Max Pressure: 12 Bar
Control Panel:
- Type: Three-in-One (Auto/Manual/Stop)
- Pressure Switches: Danfoss KP Series
- Alarms: Low/High Pressure, Motor Overload
Valves & Accessories:
- Inlet/Outlet Valve: AMICO, 4″ flanged
- Check Valve: Silent Check Valve (H41T-10/16)
- Gate Valve: Resilient Seated (Z45X-16Q)
- Flexible Connector: Rubber Adapter (KDTF 1.6×25~500)
Installation:
- Suction Pipe: 4″, straight run ≥5x pipe diameter
- Discharge Pipe: 4″
- Foundation: Concrete base with vibration pads
- Priming: Required (if not self-priming)
Environmental:
- Temperature: -20°C to 40°C
- Altitude: Up to 1000 meters
- Humidity: ≤95% non-condensing
Certifications:
- Standards: ISO 9001, ISO 14001, CE
- Fire Protection: NFPA 20 (if applicable)
Maintenance:
- Interval: 6 months or 2000 hours
- Lubrication: Oil change every 2000 hours
- Inspection: Regular checks on seals, bearings, impeller
Warranty:
-
- Period: 12 months from commissioning or 18 months from shipment
- Support: 24/7 technical assistance
For more information, visit our website: https://silverstringchemicals.com/
Connect with us on social media:
- LinkedIn: Silver String Chemicals
- TikTok: @silverstringchemicals
- YouTube: Silver String Chemicals
- Instagram: @silverstringchemicals_ssc
- Facebook: Silver String Chemicals
Contact us via email at: silverstringchemicals@gmail.com
| ALL PRICES MENTIONED ON SSC SHOP: Ex-Works Factory, Lahore, Pakistan. | ||||||
| FREIGHT CHARGES ARE EXCLUDED | ||||||
| THESE PRICES ARE EXCLUDING TAXES | ||||||
| SEARCH THE WORD YOU ARE FINDING ITEM ON PAKISTAN’S BIGGEST ONLINE SHOP | ||||||
| DELIVERY: 4 DAYS – 45 DAYS DEPENDING ON LOCAL SUPPLIES OR IMPORTED | ||||||
| WE PROVIDE SERVICES FOR TESTING AND COMMISSIONING AND FITTINGS TOO. | ||||||
| stock availbility will be checked and told to you | ||||||
| prices are last updated in January 2023 |
Vertical Turbine Pumps (500GPM With 9 Bar Pressure) – A Complete Guide
Introduction to Vertical Turbine Pumps
When it comes to fire safety and industrial water applications, Silver String Chemicals, also known as SSC GROUP, offers the most reliable and high-performance vertical turbine pumps. These pumps are essential in fire protection systems, municipal water supplies, industrial cooling, and agricultural irrigation. Our SILVER STRING FIRE SAFETY pumps are designed for high efficiency and long-lasting performance, making them an ideal choice for various industries in Lahore, Faisalabad, Karachi, Sialkot, and Islamabad.
Key Features of Our Vertical Turbine Pumps
1. High Flow Capacity & Pressure
Our vertical turbine pumps deliver 500 GPM flow rate with 9 bar pressure, ensuring reliable water movement in emergency fire situations and industrial applications.
2. Multiple Material Options
These pumps are available in stainless steel, bronze, cast iron, and ductile iron, meeting different industry requirements.
3. UL/FM Approved & LPCB Certified
At Silver String Safety, we provide pumps that comply with UL, FM, LPCB, and CE standards. Whether you need local manufacturing items, China import items, or SSC-manufactured pumps, we have all options available.
4. Application in Fire Protection Systems
Our UL/FM-approved vertical turbine pumps play a vital role in fire safety applications in textile mills, pharmaceutical industries, oil refineries, and commercial buildings.
5. Installation & Maintenance
The pumps are available in aboveground or underground installations, with oil or water-lubricated bearing systems for smooth operation.
Industries That Use Vertical Turbine Pumps in Pakistan
Our pumps are widely used in:
- Fire safety systems in Lahore, Faisalabad, Karachi, and Multan.
- Irrigation projects in Punjab and Sindh agricultural sectors.
- Industrial cooling in textile mills and sugar mills.
- Municipal water supply systems in Islamabad and Peshawar.
Why Choose Silver String Chemicals for Vertical Turbine Pumps?
- Largest supplier of fire safety pumps in Pakistan.
- Certified quality: UL, FM, LPCB, CE, China Import.
- Affordable pricing with high durability and efficiency.
- Expert technical support and installation services.
- Multiple variations: SSC Manufactured, Local, Imported.
